Indoor P1.8 LED Display Module
Indoor P1.8 LED Display Module Specifications
The Indoor P1.8 LED Display is designed for high-definition indoor visual applications where clarity, color accuracy, and smooth performance are essential. With a 1.8mm pixel pitch, it delivers crisp, vibrant images, making it ideal for corporate offices, studios, showrooms, control rooms, and exhibition halls. Its modular design, energy efficiency, and reliable performance ensure a premium indoor viewing experience at medium to close distances.
Technical Specifications
| Feature | Specification |
|---|---|
| Pixel Pitch | 1.8mm |
| Pixel Configuration | 1R1G1B |
| LED Type | SMD1010 |
| Module Size (W×H) | 288 × 288 mm |
| Module Resolution (W×H) | 160 × 160 dots |
| Module Weight | 540g |
| Pixel Density | 308,641 dots/m² |
| Brightness | ≥600 cd/m² |
| Maximum Power Consumption | 65W/piece |
| Average Power Consumption | 32W/piece |
| Refresh Rate | ≥3840Hz |
| Minimum Viewing Distance | ≥1.8 meters |
